The ESM1500 and ESM 750 are highly configurable single-column force testers for tension and compression measurement applications with capacities of 1,500lbf (6.7kN) and 750lbf (3.4kN).Suitable for laboratory and production environments apart from break testing, cycling, limit testing to a load or distance, loadholding, elongation testing, tensile testing, compression testing, and more. The available FollowMe® facilitates crosshead positioning for sample setup. Hand guided push/pull on the load moves the crosshead at a dynamically variable speed. The stands feature a unique modular controller function platform. Functions such as travel measurement, cycling, etc. are offered individually, accommodating a wide range of budgets and applications.Force and travel data can be output to a PC for graphic and analysis using MESUR™gauge software, or fully control the stand by PC through a custom-written program in any language supporting ASCll communications.
United High Capacity Smart Universal Hydraulic Floor Model DFM tension and compression testing machines with computer control are available with capacities from 300 kN (67,500 lbf) to 2,000 kN (450,000 lbf). Available with extended columns. United 'SMART' Testing Machines meet the requirements of ASTM E-8, ASTM E-9 and ASTM E-83.
United's Load Cells are designed to precisely measure the amount of force (load) applied to the specimen being tested. Available in single or dual bridge, United load cells offer the flexibility of using two readouts simultaneously, if desired. Constructed to meet ASTM E-4 requirements.
United SFM Smart Electro-Mechanical Universal Floor Models are the logical choice when maximum crosshead travel and load frame capacity are required. The United SFM Models SFM Universal Testing Machines offer a choice of five standard load frame capacities ranging from 1,000 lbf (4.45 kN) to 135,000 lbf (600 kN).Testing can be done in tension and/or compression. United 'SMART' Testing Machines meet the requirements of ASTM E-8, ASTM E-9 and ASTM E-83.
Servo-Controlled Hydraulic Floor Model 2000 kN (450,000 lbf). United SHFM 1000 and SHFM 2000  kN Hydraulic Testing Machines have four columns and test in Tension or Compression (Universal). The SHFM Hydraulic testing systems are fully accessorized and include the following at no additional cost: Hydraulic Grips with inserts for both flat flat and round test specimens, Flex Fixture and Compression Plates. United 'SMART' Testing Machines meet the requirements of ASTM E-8, ASTM E-9 and ASTM E-83.
The United Digital Speedy Tester Model LCH-10 - 50 kN,  LCH-20 - 100kN, LCH-30 - 150kN and LCH-60 - 300 kN are hydraulic testing machines incorporating a highly accurate, built-in digital information system for the display of test data. Designed to perform a variety of tests, the versatile, easy-to-use Speedy Tester can be fitted with various types of grips and fixtures to accommodate a wide range of materials and applications. The Speedy is a Tension Tester, outfitted with a compression cage it can also perform compression tests.
Mark-10 Series TT03 Torque Gauges designed for clockwise and counter-clockwise torque testing applications in virtually every industry, with capacities from 10 ozFin to 100 lbFin.
Series 4 Performance Force Gauges feature a sampling rate of 3,000  Hz and +/-0.2% accuracy, producing reliable, accurate results in a wide range of applications. Set point indicators with outputs are ideal for pass/fail testing, while an analog load bar provides graphical representation of applied load. Data memory for 50 readings is also provided, along with data output capability via USB, RS-232, Mitutoyo analog output, AC Adapter charger and carrying case.
The United TRU-BLUE Rockwell Hardness Tester is computer controlled (closed loop) application of forces are via load cell measurement. The Tester has a 4 x 20 bright vacuum fluorescent display. Front panel controls with Piezo-Electric switches. Auto self-test and last test setup recall at startup. Removable parts clamp used to secure irregular shaped or oversize test specimens. Logical setup and operating menu from front panel keys. Throat depth is 5.5 inches. Optional 9.5 inch throat depth is available.
The MicroStar SH-500 Leeb Hardness Main Features: Multiple Languages selection, memory for 2000 Test Results, saved information including single Measured Value, Mean Value, Impact direction, number of Impacts performed, Material and Hardness. Order No.: 76-05-00
The MicroStar Ultrasonic Portable Hardness Tester Model SU-300 is designed to test hardness of metals on flat, round, thin or large surfaces.
Series R50 smart sensors measure bi-directional torque for a wide variety of applications across virtually all industries. Contain a Jacobs chuck for up to 0.5in (12.7mm) diameter samples, bits or fixtures. The sensors can be used as hand held devices, or mounted to a test stand.
MicroStar Digital Brinell Hardness Tester Model SHB-3000D Load Cell Force application and measuring system. Enclosed load cell application. Automatic application, holding and removal of loadd. Accuracy conforms to ASTM-E10, ISO 6505.
AutoVicky ZVK-1050AF series are fully automatic Micro & Macro Vickers and Knoop Hardness Tester with motorized X-Y stage, auto-focus system, auto-indentation and Twin Vickers / Knoop Indenters. Accuracy conforms to ASTM-E-92/E-384 and ISO 6507, 9385, 4545..
Pneumatic Clamping Operation with 1-14" Female Thread on both ends.
MicroStar Series MHV-1000Z/ MHV-1000ZK precision Micro Vickers & Knoop Hardness Machines with integrated technology of optics, mechanics and computations. Conforms to ASTM-E-92/-E384 and ISO 6507,9385, 4545.
Convenience and reliability is what the Clark Portable " Rockwell" Tester, Model CPT, provides the user.  It has the ability to test both inside and outside surfaces at any angle without affecting accuracy.  Quick change indenter, easy to read dial indicators, and finger tip loading make the CPT a handy and efficient form of testing large and inaccessible parts.
Accurate - Calculated to 1/2 of 1% of load. Can be used for higher loads up to 3,000 kg. Versatile - Can be used in virtually any position. Durable - Some King Portable Brinell testers have been working over 60 years. Permanence - Impressions can be checked anytime.
MicroStar PHR series is an accurate and lightweight portable Hardness Tester designed for testing where limited clearance is available. This Rockwell Tester it is not only suitable for measuring small samples but also large parts and irregular parts can be adopted. The tester offsets the problem that the rebound hardness tester poses in accurate testing of small parts.
The United Hammer Brinell Impact Hardness Tester PHB-1 is economical and easy to use. It applies force to the Indenter by the operator using a Hammer or Clamping Device. The force applied is controlled using a calibrated shear pin. When the load applied reaches the shear pin's limit, the shear pin breaks.
PHR series are portable Rockwell Hardness Testers for the measurement of metal and plastic materials these Rockwell Hardness Testers are not only suitable to measure small parts, but also to measure large and fixed parts.
Scope of application, testing of hardness of small or thin samples and small areas of larger samples.
Micro Star HV-10 Series are semi Automatic smart Vickers Hardness Testing machines, that adopt the close-loop force sensor to replace are controlled the traditional quality weight. This innovative design makes the instrument more accurate. Selection of testing force and dwell time are controlled and monitored on the front panel automatic during process of loading, dwell and unloading.
LFM Electromechanical Floor Standing Machines up to 125 kN This Series offers ultra-high flexibility and modularity making this model the perfect platform for a wide spectrum of users and applications ranging from demanding research projects to high-volume quality control.
Micro Star Digital Micro Vickers Hardness Tester MicoVicky is affordable Micro Vickers Hardness Tester, has a color touch screen, auto hardness conversion to other scales. Depth and hardener layer can be automatically calculated and data can be viewed and printed via Bluetooth. Automatic loading, dwelling and unloading, simple operation no human operator error. The updated manual lifting system has no gap. Equipped with upgraded optical system that provides clear image of indentation and improved accuracy of the measurement.
