Composites
The DSTM system comprises of an SSTM machine, a United load cell, and the Datum 5i operation software.
United High Capacity Smart Universal Hydraulic Floor Model DFM tension and compression testing machines with computer control are available with capacities from 300 kN (67,500 lbf) to 2,000 kN (450,000 lbf). Available with extended columns. United 'SMART' Testing Machines meet the requirements of ASTM E-8, ASTM E-9 and ASTM E-83.
The United Automatic Carbon Fiber Tester is designed to automatically (without operator intervention) test up to 200 specimens of carbon fiber in one setup. For easy record keeping and generating reports, specimen data are entered into the test software via barcode. The diameter of each fiber specimen is measured by a laser diffraction measuring system.
United SFM Smart Electro-Mechanical Universal Floor Models are the logical choice when maximum crosshead travel and load frame capacity are required. The United SFM Models SFM Universal Testing Machines offer a choice of five standard load frame capacities ranging from 1,000 lbf (4.45 kN) to 135,000 lbf (600 kN).Testing can be done in tension and/or compression. United 'SMART' Testing Machines meet the requirements of ASTM E-8, ASTM E-9 and ASTM E-83.
Servo-Controlled Hydraulic Floor Model 2000 kN (450,000 lbf). United SHFM 1000 and SHFM 2000  kN Hydraulic Testing Machines have four columns and test in Tension or Compression (Universal). The SHFM Hydraulic testing systems are fully accessorized and include the following at no additional cost: Hydraulic Grips with inserts for both flat flat and round test specimens, Flex Fixture and Compression Plates. United 'SMART' Testing Machines meet the requirements of ASTM E-8, ASTM E-9 and ASTM E-83.
Compressive Properties of Unidirectional or Crossply Fiber Resin Composites.
United STD-75-CF Compression Fixture (ASTM-D-3410).
Designed for materials and components testing the LFM-TOP Dual Column Table-Top Systems can be used over a range of force applications up to 125 kN. The LFM-TOP test systems are supplied with two backlash-free ball screws and additional two guidance columns providing suitable load frame stiffness as required for table top design. The mobile crosshead is driven by a state-of-the-art brushless / maintenance free AC Servomotor providing high positioning accuracy and repeatability, faster starts and stops, best control, and highest accuracy at extremely low noise level.
LFM Electromechanical Floor Standing Machines up to 125 kN This Series offers ultra-high flexibility and modularity making this model the perfect platform for a wide spectrum of users and applications ranging from demanding research projects to high-volume quality control.
Micro Star Digital Micro Vickers Hardness Tester MicoVicky is affordable Micro Vickers Hardness Tester, has a color touch screen, auto hardness conversion to other scales. Depth and hardener layer can be automatically calculated and data can be viewed and printed via Bluetooth. Automatic loading, dwelling and unloading, simple operation no human operator error. The updated manual lifting system has no gap. Equipped with upgraded optical system that provides clear image of indentation and improved accuracy of the measurement.
